| Specification | 中心距 – 1000U mm | 中心距 – 2000U mm | 中心距 – 3000U mm | 中心距 – 4000U mm | |
|---|---|---|---|---|---|
| 加工能力 | 最大回轉直徑 | 1040 mm / 40.94 in | 1040 mm / 40.94 in | 1040 mm / 40.94 in | 1040 mm / 40.94 in |
| 最大加工直徑 | 910 mm / 35.830 in | 910 mm / 35.830 in | 910 mm / 35.830 in | 910 mm / 35.830 in | |
| 最大加工長度 | 1082 mm / 42.600 in | 2075 mm / 81.690 in | 3210 mm / 126.380 in | 4099 mm / 161.380 in | |
| 主軸 | 卡盤尺寸 | 18 in | 18 in | 18 in | 18 in |
| 最大轉速 | 1600 rpm | 1600 rpm | 1600 rpm | 1600 rpm | |
| 上刀塔 | 刀具數量 | 12 | 12 | 12 | 12 |
| 最大轉速 | 4000 rpm | 4000 rpm | 4000 rpm | 4000 rpm | |
| 進給軸 | 行程(X軸) | 465 mm / 18.31 in | 465 mm / 18.31 in | 465 mm / 18.31 in | 465 mm / 18.31 in |
| 行程(Z軸) | 1175 mm / 46.26 in | 2165 mm / 85.24 in | 3300 mm / 129.92 in | 4190 mm / 164.96 in | |
